Verified product data
Specifications
Input
- Operating voltage
- 12-24V DC
- Working current
- 40mA maximum
Mechanical
- Product size
- Diameter 58 x 34.5mm
- Cut-out
- Diameter 45mm
Sensor
- Maximum detection radius
- 0.25m at 3m mounting height
- Daylight threshold
- 0-50Lux / Disable
- Detection technology
- ToF occupancy detection and daylight sensing
Control
- Output signal
- RS485
Installation
- Mounting height
- 2.5-3m (typical 3m)
- Installation mode
- Flush or surface mounting
Environment
- IP rating
- IP20
