Standalone Sensors
MSA223 A
Standalone Sensors
MSA223 A is designed for professional lighting-control and building-automation applications. Supported technologies: 24GHz, Presence, Bluetooth.
Verified product data
Specifications
Input
- Operating voltage
- 100-240VAC
- Working current
- 50mA maximum
Mechanical
- Product size
- Diameter 70 x 48mm
- Cut-out
- Diameter 55mm
Sensor
- Maximum detection radius
- Motion / minor motion / presence: 3.5m at 3m mounting height
- Daylight measurement
- 0-2000Lux
- Detection technology
- 24G Hz presence detection and daylight sensing
Control
- Output / ecosystem
- Mijia Bluetooth 5.0 / Mesh 1.0
Installation
- Mounting height
- 2.5-4m (typical 3m)
- Installation mode
- Flush mounting
Environment
- IP rating
- IP20
