Standalone Sensors
MSA056K 99
Standalone Sensors
MSA056K 99 is designed for professional lighting-control and building-automation applications. Supported technologies: 5.8GHz, Motion, KNX.
Verified product data
Specifications
Input/Output
- Voltage range
- KNX bus power supply
- Operating current
- 8±1mA
- Output signal
- KNX bus communication
Sensing parameters
- Working frequency
- 5.8G Hz±75MHz
- Transmit power
- 1mW Max
- Detection Area
- ETS settings: 8% 16% 24% 32% 40% 48% 56% 64% 72% 80% 88% 100%
- Delay setting (Hold Time)
- ETS setting: 1s-30min (the front end of this product has a fixed delay of 5s, so when setting 1s, the actual delay will be 6s)
- Detection range (100% sensitivity, radius)
- Mobile (3m high): 4-5m
- Remote control function
- Support
- Installation height
- 2.5-4m, typical value: 3m
- 3dB beam angle
- 90° (XZ plane) 95° (YZ plane)
Usage environment
- Hole size
- 55-65mm
- Working environment temperature
- 0℃...+50℃
- Storage temperature
- -40℃...80℃ Humidity: ≤85% (non-condensation)
Certification Standard
- Comply with certification
- FCC/RED
- Environmental protection requirements
- Comply with EU RoHS requirements
- Protection level
- IP20
