Luminaire Control Sensors
MC098S F1
Luminaire Control Sensors
MC098S F1 is designed for professional lighting-control and building-automation applications. Supported technologies: 5.8GHz, ON/OFF.
Verified product data
Specifications
Technical specifications
- Model
- MC098S F1
- Rated voltage
- 230VAC
- Standby power consumption
- ≤0.5W
- Working mode
- ON/OFF
- Load type
- Capacitive/Resistive
- Load power
- 400W @230VAC (capacitive load) 800W @230VAC (resistive load)
- Working frequency
- 5.8 G Hz ±75 MHz, ISM band
- Transmit power
- 1mW Max
- Installation height
- Typical value: 3m (6m Max)
- Installation dimensions
- 77.0*36.0*25.6mm
- Net weight
- 45g±3g
- Lifespan
- 5-year warranty @Ta 230V full load
