Luminaire Control Sensors
MC079D RC ZZi
Luminaire Control Sensors
MC079D RC ZZi is designed for professional lighting-control and building-automation applications. Supported technologies: 5.8GHz, Tuya, Zigbee.
Verified product data
Specifications
Technical specifications
- Model
- MC079D RC ZZi
- Voltage range
- 11-13V DC
- Rated voltage
- 12V DC
- Standby power consumption
- ≤0.5W
- Module name
- ZigBee module
- Transmission distance
- Visible distance>150m
- Transmit power
- 3mW
- Detection range (100% sensitivity radius)
- Ceiling installation 10m high: 0.3m/S ≥4m, 1m/S ≥3m
- Protection level
- IP20
- Comply with certification
- CE
- Lifespan
- 5-year warranty @Ta 12V full load
Zigbee module
- Working frequency
- 2.4-2.484G Hz
Sensor parameters
- Working frequency
- 5.8 G Hz ±75 MHz, ISM band.
