Standalone Sensors
M2
Merrytek scene presence sensor (Mi Home compatible)
M2 is designed for professional lighting-control and building-automation applications. Supported technologies: 24GHz, Presence, Motion.
Verified product data
Specifications
Technical specifications
- Model
- M2
- Appearance size
- Φ60x25.8mm
- Product net weight
- 44.8g
- Power supply
- 5V DC (Type-C)
- Rated power
- ≤2W
- Installation height
- 1.5-2m Typical value: 1.8m
- Wireless protocol
- Wi-Fi IEEE 802.11 b/g/n 2.4G Hz
- Radar frequency
- 24G Hz-24.25G Hz ISM band
- Detection range (100% sensitivity, radial)
- Movement/micromotion/existence (wall mounted 1.8m high): 6m
- Detection angle
- Horizontal 120°
- Light sensitivity range
- 0-1200Lux
- Operating temperature
- 0℃~50℃
- Implementation standards
- GB 4943.1-2022
- CMIIT ID
- 24J116XQG002 (wireless communication module included in the sensor)
