Smart Drivers
KL35C-PDii
DALI dimming power - DT6
KL35C-PDii is designed for professional lighting-control and building-automation applications. Supported technologies: DALI, IP20.
Verified product data
Specifications
Technical specifications
- Dimming interface
- Junior PUSH, DALI
- Dimming range
- 2%-100%
- Input voltage
- 220-240Vac, 50Hz / 60Hz
- Standby power consumption
- <0.5W
- Work efficiency
- 87% Max. @230Vac
- Output current/voltage/power
- 700mA / 3-40Vdc / 28W 750mA / 3-40Vdc / 30W00mA / 3-40Vdc / 32W 850mA / 3-40Vdc / 34W900mA / 3-38Vdc / 34W 950mA / 3-36Vdc / 34W1000mA / 3-35Vdc / 35W 1050mA / 3-33Vdc / 35W
- Safety Standard
- EN61347-1, EN61347-2-13
- EMC standards
- EN55015, EN61547, EN61000-3-2, EN61000-3-3
- DALI standard
- ICE 62386 102, 207, 251, 252, 253
- Certification
- SAA, CE, CB
- Operating temperature
- -25℃-+50℃
- IP level
- IP20
- Dimensions
- External: 136*42*24 Internal: 96*42*24
